ProSecure Unified Threat Management (UTM) Appliance

View the System Status Screen

To view the System Status screen, select Monitoring > System Status. The System Status

tabs display, with the System Status screen in view:

Figure 270.

The following table explains the fields of the System Status screen:

Table 117. System Status screen fields

Item Description

Status

System The current CPU, memory, and hard disk usage. When usage is within safe limits,

the status bars show green.

Application Control Status The status of application control (ON or OFF).

Application Control Mode The application control mode (GLOBAL or PROFILE).

Default Chapter2
