LAN Configuration

98

ProSecure Unified Threat Management (UTM) Appliance

Figure 54.

3. Enter the settings as explained in the following table:

Table 21. Edit VLAN Profile screen settings

Setting Description

VLAN Profile

Profile Name Enter a unique name for the VLAN profile.

Note: You can also change the profile name of the default VLAN.
