Oki MC860 Maintenance Manual

43967002TH Rev.1
115 /
Oki Data CONFIDENTIAL
3. Installation
Scanner Setup
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
Other Settings Rotate Tx OFF
ON
Set the rotary transmission.
ECM Mode OFF
ON
Set ECM mode.
PreFix 0000 Set prefix.
Received Time
Stamp
OFF
ON
Set reception time stamp.
Print Check message OFF
ON
Set check message print.
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
Default
Settings
(Common
to Scan
To E-mail
and Scan
To USB
memory)
Doc. Type Doc. Type Text
Text/Photo
Set default setup of selecting image
quality when scanning document.
Removal for
Background
& Show-
Through
(sTHR)
Auto
OFF
1
2
3
4
5
sTHR
Set default setup of background/offset
phenomenon removal.
Density -3
-2
-1
0
+1
+2
+3
Set default setup of density.
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
Default
Settings
(Common
to Scan
To E-mail
and Scan
To USB
memory)
Resolution 75 dpi
100 dpi
150 dpi
200 dpi
300 dpi
400 dpi
600 dpi
Set default setup of resolution.
Scan Size Auto
Letter
Letter
Tabloid
Legal 14
H.LTR
A3
B4
A4
A4
B5
B5
A5
A5
Set default setup of document scanning
size.
Cont. Scan OFF
ON
Select default setup to inquire or not
to inquire if next page of document is
ready.
Direction Left Edit
Top Edit
Set default setting of orientation of
document that is set on glass, and set
orientation of image.
Left end It is defined at the top end of
image that has loaded the scanning
start position.
Top end It is defined at the left end of
image that has loaded the scanning
start position.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
