7. Troubleshooting
Displayed message Descriptions
Print page ppp No. of
Copies iii/jjj
Collate printing.
"Print page" means the current number of printing page (ppp).
"No of Copies" is displayed as "iii/jjj".
iii: The number of copy in printing.
jjj: the total number of printing.
The unit of "Print page" is "Impression".
In simplex printing, "Print page" counter is increased by 1
when the paper exited from fuser.
In duplex printing, "Print page" counter is increased by 2 when
the paper exited from fuser (after the back side printed out).
Print page ppp No. of
Copies kkk/lll
Copy printing.
"Print page" means the current number of printing page (ppp).
"No of Copies" is displayed as "kkk/lll".
kkk: The number of pages in printing.
lll: The total number of printing.
The unit of "Print page" is "Impression".
In simplex printing, "Print page" counter is increased by 1
when the paper exited from fuser.
In duplex printing, "Print page" counter is increased by 2 when
the paper exited from fuser (after the back side printed out).
Verifying data. Indicates that the integrity of print data for encrypted
authentication is being verified (for corruption and tampering).
Deleting data. Indicates that job cancellation has been instructed and data is
being ignored until the job completion.
Deleting data. Indicates if JAM occurs when Jam Recover is OFF, that job
cancellation has been instructed and data is being ignored
until the job completion.
Deleting data. Indicates a job being cancelled due to no print permit. (Related
to JobAccount)
1. A job received from a user who is denied printing.
2. A color job received from a user who is denied color
printing.
Warming Up. Shows cooling down status.
It is cautious of a period following "Preparing".
Warming Up Warming up.
Displayed message Descriptions
Warming Up Indicates that printing has been suspended for a while due to
high temperature of the drum, or the printer is in a wait state
to cope with heat at the time of switching narrow paper to
wide paper.
Blank A MC860 is in power save mode.
LCD back light is turned off.
Red LED is turned on.
Preparing Executing Auto Color Adjusting
Preparing Executing Auto Density Adjustment.
Status code 10988 corresponds to density reading, thereto
10994 corresponds to density adjusting.
PU downloading Downloading PU F/W (This is not user-level error)
This function is secret to users. Therefore, this status does not
occur in a user environment.
Disk Security Mode Securty Kit is installed.
This status message is always displayed in printer stand-by
screen.
Updating ROM
Please keep power ON.
Downloading scanner unit (Scanner, Fax, Panel) FW.
Please Log in Requests to do user authentication.
Entry screen of
Admin Password
Requests to enter administrator password for the moving to
"Admin Setup" menu.
Access control became
valid.
Indicates that PIN or User mode is enabled.
This message isn't displayed when the setting is canged from
Web page.
Access control became
invalid.
Indicates that PIN or User mode is disabled.
This message isn't displayed when the setting is canged from
Web page.
Cancelling Indicates that copy job is canceling.
This message displayed when the copy is canceled by
operator.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
