Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
291 /
7. Troubleshooting
Displayed message Descriptions
<Scan To Mail/ Network PC
Screen>
Scanning
Press Stop Key to stop
scannng.
%LOCATION_INFO%
Page :%SCAN_PAGE%
Doc.Size:%DOC_SIZE%
------------------------------
<Fax Sending Screen>
Scanning
Press Stop Key to stop
scannng.
Comm.No.:%COMM_NO%
%LOCATION_INFO%
Page :%SCAN_PAGE%
Doc.Size:%DOC_SIZE%
Indicates that it is scanning of documents.
The screen image in ScanTo: "Sample Screen" sheet - no.17
The screen image in Fax Sending: "Sample Screen" sheet -
no.16
The unit of "Page" is "Impression".
In duplex scanning, "Page" counter is increased by 1 when
the front side of sheet scanning started, and the counter is
increased by 1 when the back side scanning started.
%LOCATION_INFO%: Location Information (Scan To Mail,
Scan To Network PC, Fax sending only)
%COMM_NO%: the number of communication(Fax Sending
only)
%SCAN_PAGE%: the number of current scanning page.
%DOC_SIZE%: Document size
Scan Size setting is "Auto": the detected document size.
Scan Size setting isn't "Auto": the selected scan size.
Scan Pages sss PrintPages
ppp Copy aa/bb
Indicates that it is copying.
sss: the number of current scanning page.
ppp: the number of current printing page.
aa: the number of current printing.
bb: the total number of printing.
The unit of "Scanned pages" is "Impression".
For example, in duplex scanning, "Scanned pages" counter is
increased +1 at the front side of sheet scanning started, and
the counter is increased +1 at the back side scanning started.
The unit of "Print pages" is "Impression".
In simplex printing, "Print page" counter is increased by 1
when the paper exited from fuser.
In duplex printing, "Print page" counter is increased by 2
when the paper exited from fuser (after the back side printed
out).
Displayed message Descriptions
Scanning
Press Stop Key to stop
scannng.
Page :%SCAN_PAGE%
Doc.Size:%DOC_SIZE%
Indicates that it is scanning in ScanTo USB Memoy.
The unit of "Page" is "Impression".
For example, in duplex scanning, "Paget" counter is increased
+1 at the front side of sheet scanning started, and the counter
is increased +1 at the back side scanning started.
%SCAN_PAGE%: the number of current scanning page.
%DOC_SIZE%: Document size
Scan Size setting is "Auto": the detected document size.
Scan Size setting isn't "Auto": the selected scan size.
<Copy Screen>
Set next document.
------------------------------
<Scan To, Fax Sending
Screen>
Set next document.
Set documents and press
[Scan next page].
This screen is displayed at the time of the scanning completed
in Job Build = ON.
Copy: "Sample Screen" sheet - no.28
ScanTo: "Sample Screen" sheet - no.29
Fax Sending: "Sample Screen" sheet - no.30
Cancelling Indicates that the scanning for Scan To USB memory is
canceling by the pressing Stop key.
Data Writing to USB
Memory
Indicates that it is wrighting the image file to USB memory
after the scanning completed.
The cancel operation by STOP key pressing is unsupported
during the writing to USB memory.
Please set document and
press Start Key.
Indicates that it is waiting Scan To Local PC started by user.
The selected function will be started by start key pressed.
This message is displayed when the application button
([Application], [Folder], [E-mail], [PC-FAX]) is selected in Scan
To Local PC stand-by screen.
Connecting to PC Indicates that it is connecting to PC.
This message will be displayed at Start key pressed after the
orignal document set.
Called Indicates that tha fax receiving started.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
