7. Troubleshooting
Displayed message Descriptions
Receiving
SIZE MODE Prrr
Indicates that it is receiving fax date.
SIZE: size of documents
Mode: Resolution of the receiving fax data
rrr: number of the current receiving page
x x x x x x x x Transmitting Indicates that it is calling.
x x x x x x x x : fax number of the calling.
No destination information.
Transmitting
SIZE MODE Pppp/ttt
Indicates that it is sending fax date.
SIZE: size of documents
Mode: Resolution of the receiving fax data
ppp: number of the current sending page
ttt: number of the total pages scanned
Cancelling Indicates that the scanning for fax senfing is canceling by
pressing Stop key.
Canceled Indicates that the scanning for fax senfing is canceled.
Deleted Indicates that the calling is canceled.
This message is displayed when the Stop key is pressed
during the calling.
Deleted Indicates that the fax sending is canceled.
%STATUS% Indicates that the details of network communication.
%STATUS%
E-mail transmission in progress.
Transmission in progress.
POP reception in progress: indicates that receiving from Mail
Server.
SMTP reception in progress: indicates that receiving from
Mail Server.
Transmission in progress: indicates that data sending via
network.
The cancel operation by STOP key pressing is unsupported
during Email and fail sending.
Authenticating Indiates that it is authenticating via network.
This message is dsplayed until the login completed.
Displayed message Descriptions
Connecting to Server Indicates that connecting to mail server.
The cancel operation by STOP key pressing is unsupported
during the connecting to mail server.
Cancelling transmission. Indicates that Email sending is canceling.
This massage is displayed when an error is occurred during
Email sending.
The key operation is disableed during this message displayed.
Searching Indicates that connecting to LDAP server.
nnnnnnnnnn: LDAP server name or IP address of LDAP
server.
Searching Indicates that searcing addresses by LDAP server.
Searching was cancelled. Indicates that address search is canceled by the pressing
Stop key.
Connecting to Server Indicates that connecting to file server.
The cancel operation by STOP key pressing is unsupported
during the connecting to file server.
Cancelling transmission. Indicates that file sending is canceling.
This message is displayed when an error is occurred during
file sending.
The key operation is disableed during this message displayed.
SIP update in progress. Indicates that downloading the SIP firmware data.
Address Book Printing Indicates that printing of E-mail address list and Group
address list that they are registered in Address Book.
Speed Dial List Printing Indicates that printing of fax location list that is registered in
Speed dial.
Group List Printing Indicates that printing of fax location list that is registered in
Group dial.
Transmit Journal Printing Indicates that printing of fax sending result list.
Receipt Journal Printing Indicates that printing of fax receiving result list.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
