Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
294 /
7. Troubleshooting
Warning
Displayed message Descriptions
Please install %COLOR%
Toner.
Toner amount is low. Displayed in a combination of other
message in the first line.
In case of MENU "Admin Setup"-"Printer Setup"-"Print Menu"-
"Printer Adjust"-"Low Toner"=Stop, Alarm LED blinks and the
printer shifts to OFF Line.
When an ONLINE switch is pushed, or when arbitrary errors
occur and the error is canceled, an off-line state is canceled,
and printing is continued until it is set to Toner Empty(no.143).
Arbitrary errors are errors of no.114-173, 358 and 359.
"TONER LOW" status occurs when the power is on, the LED
of Alarm in a case of MENU "Admin Setup"-"Printer Setup"-
"Print Menu"-"Printer Adjust"-"Low Toner"=Stop is blinked and
go back to the off line after the initializing process.
It is possible to operate untill "TONER EMPTY" by pressing
"ONLINE switch".
Moreover, when set as "Admin Setup"-"Management"-
"System Setup"-"Near Life LED"=Disable, Alarm LED is
switched off.
%COLOR%
Y
M
C
K
Please install %COLOR%
Toner.
This warning is displayed at Cover Open/Close or Power
OFF/ON after a waste-toner full error (no.142) occurs. (Not
occur for Black.)
Displayed in a combination of other message in the first line.
As long as this warning is being displayed, a waste toner full
error occurs , the printer shifts to Offline and stops each time
it has printed about 50 copies.
%COLOR%
Y
M
C
Displayed message Descriptions
Please install %COLOR%
Toner.
It shows the toner cartridge of authorized 3rd party. (RFID
Licensed to 3rd party)
%COLOR%
Y
M
C
K
%COLOR% Toner Regional
Mismatch.
The Region ID of toner cartridge is not proper to the
distribution channel.
%COLOR%
Y
M
C
K
Non Genuine %COLOR%
Toner.
The chip of RFID is not compatible.
%COLOR%
Y
M
C
K
Error Postscript Interpreter detects an error due to the following reason. Receive
data after this is ignored until the job completion. When the job
is completely received, this is automatically cleared.
- The job has a grammatical error.
- The page is complicated, and VM was used up.
%COLOR% Image Drum
Near Life.
The life of the drum (warning). Displayed in a combination of
other message in the first line. The printer stops at the point
when it reaches the drum life (Shifts to error, OFF-LINE.)
Moreover, when set as "Admin Setup"-"Management"-
"System Setup"-"Near Life LED"=Disable, Alarm LED is
switched off.
%COLOR%
Y
M
C
K

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
