Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
295 /
7. Troubleshooting
Displayed message Descriptions
Fuser Unit Near Life. Notifies the fuser unit is near its life.
Moreover, when set as "Admin Setup"-"Management"-
"System Setup"-"Near Life LED"=Disable, Alarm LED is
switched off.
Belt Unit Near Life. Notifies the belt unit is near its life. This is a warning; thus,
printing will not stop.
Moreover, when set as "Admin Setup"-"Management"-
"System Setup"-"Near Life LED"=Disable, Alarm LED is
switched off.
Please change Fuser Unit. Notifies the life of the fuser unit (warning).
This appears when the cover was opened and closed just
after the fuser life error occurred.
Please change Belt Unit. Notifies the life of the belt unit (warning).
This appears when the cover was opened and closed just
after the belt life error occurred.
%COLOR% Toner Empty Notifies the toner is empty. This is a warning only.
This appears when the cover was opened and closed just
after the toner empty error occurred.
%COLOR%
Yellow
Magenta
Cyan
Black
%COLOR% Toner not
installed.
Notifies the toner cartridge is not installed. This is a warning
only.
%COLOR%
Y
M
C
K
Displayed message Descriptions
Please install New
%COLOR% Image Drum.
Notifies the life of the drum. This is a warning only.
This appears when the cover was opened and closed just
after the drum life error occurred.
%COLOR%
Y
M
C
K
Belt Reflex Error Belt Reflex Check Error.
PU firmware does not notify this warning to CU firmware at
the time of Shipping Mode. Therefore, this status does not
occur in a user environment.
Density Shutter Error2 Density Adjustment Shutter Error 2. Error that does not occur
at user level.Displayed only in FactoryMode.
PU firmware does not notify this warning to CU firmware at
the time of Shipping Mode. Therefore, this status does not
occur in a user environment.
Density Shutter Error1 Density Adjustment Shutter Error 1. Error that does not occur
at user level.Displayed only in FactoryMode.
PU firmware does not notify this warning to CU firmware at
the time of Shipping Mode. Therefore, this status does not
occur in a user environment.
Density Color Calibration Density Adjustment Color Calibration Error. Error that does
not occur at user level.Displayed only in FactoryMode.
PU firmware does not notify this warning to CU firmware at
the time of Shipping Mode. Therefore, this status does not
occur in a user environment.
Density Color Sensor Error Density Adjustment Color Sensor Error. Error that does not
occur at user level.Displayed only in FactoryMode.
PU firmware does not notify this warning to CU firmware at
the time of Shipping Mode. Therefore, this status does not
occur in a user environment.
Density Black Calibration Density Adjustment Black Calibration Error. Error that does
not occur at user level.Displayed only in FactoryMode.
PU firmware does not notify this warning to CU firmware at
the time of Shipping Mode. Therefore, this status does not
occur in a user environment.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
