Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
303 /
7. Troubleshooting
Error Code
Displayed message Descriptions
(ONLINE) Wait a Moment
Network Configuration
Writing
This appears during the NIC configuration data is
storing into the flash memory, as the setting was
changed.
(ONLINE) Wait a Moment
Network Initializing
This appears when the NIC initialization is occurred, as
the setting was changed.
(ONLINE) SIP Firmware Missing. Indicates that the firmware in MZA board can not be
detected.
310
311
Cover Open
Close the blinking cover
The cover is open.
Error 310 : Top Cover
Error 311 : Front Cover
316 Cover Open
Close the blinking cover
The cover is open.
Error 316 : Duplex Unit
320 Please check Fuser Unit. The fuser unit is not correctly installed.
321 Power Off and Wait for a
while
Motor Driver IC overheat is detected.
330 Please change Belt Unit. The belt unit is not correctly installed.
340
341
342
343
Please check
%COLOR% Image
Drum.
The image drum is not correctly installed.
Error 340 : Y
Error 341 : M
Error 342 : C
Error 343 : K
348 Please check Fuser Unit:
%ERRCODE%
The engine detects the fuser unit error.
It recovers, when a value is able to be normally read
by re-reading after cover closing. When not recovering,
exchange of a fuser unit is needed.
%ERRCODE% specifies 3 digits error code.
350
351
352
353
Please install New
%COLOR% Image
Drum.
The life of the image drum (Alarm)
Error 350 : Y
Error 351 : M
Error 352 : C
Error 353 : K
Warning status takes effect at Cover Open/Close.
Error Code
Displayed message Descriptions
354 Please change Fuser
Unit: %ERRCODE%
Notifies the fuser has reached its life. This is the error
displayed based on the counter to indicate that the
fuser has reached its life, and printing will stop.
Warning status takes effect at Cover Open/Close.
This error will occur on some user setting mode.
%ERRCODE% specifies 3 digits error code.
355 Please change Belt Unit:
%ERRCODE%
Notifies the transfer belt has reached its life. This is the
error displayed based on the counter to indicate that the
belt has reached its life, and printing will stop.
Warning status takes effect at Cover Open/Close.
%ERRCODE% specifies 3 digits error code.
356 Please change Belt Unit:
%ERRCODE%
Indicates waste toner full. Warning status takes effect
only once at Cover Open/Close, and the error occurs
again when about 500 copies have been printed.
%ERRCODE% specifies 3 digits error code.
360 Install Duplex Unit Duplex unit is open (removed).
This message is displayed the duplex unit is removed
under the error status (paper jam, cover opend e.t.c.)
occurred.
If the duplex unit is removed without error status,
"Inspection is required. 181: Fatal Error" is displayed.
370
371
373
Paper jam!
Open & check the
blinking cover.
Jam has occurred nearby DUPLEX unit.
Error 370 : Duplex Reversal
Error 371 : Duplex Input
Error 373 : Multifeed into Duplex (Duplex Remain Jam)
Alarm Buzzer is sounded, when "Admin Setup" -
"Management" - "Sound Setup" - "Paper Jam Alert"
setting is "ON".
372 Paper jam!
Open & check the
blinking cover.
Jam has occurred nearby DUPLEX unit.
Error 372 : Misfeed from Duplex
Alarm Buzzer is sounded, when "Admin Setup" -
"Management" - "Sound Setup" - "Paper Jam Alert"
setting is "ON".

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
