Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
305 /
7. Troubleshooting
Error Code
Displayed message Descriptions
423 Trust Paper Error
Trust Paper Error:
%ERRCODE%
This error occurs when capacity of specified information
to be embedded exceeds the capacity that can be
embedded in the woven pattern. A printing operator
must reduce data to be embedded in the woven pattern.
Displays a warning on the operation panel as waiting
for key press. Does not print the job that is being
processed. (The same operation as job reset)
424 Trust Paper Error
Trust Paper Error:
%ERRCODE%
Density of the destination image for woven pattern is
greater than that of the woven pattern. A user must
take measures such as increasing density of the woven
pattern or decreasing density of the input image.
Displays a warning on the operation panel as waiting
for key press. Does not print the job that is being
processed. (The same operation as job reset)
425 Trust Paper Error
Trust Paper Error:
%ERRCODE%
The area specified for tampering verification is incorrect.
This error occurs when an image is pushed away or the
unprintable area is specified.
426 Protec Paper Error:
Protec Paper Error:
%ERRCODE%:
Size of information to be embedded is greater than
paper size. It is required to reduce information to be
embedded or increase print paper size to make prints.
427 Protec Paper Error:
Protec Paper Error:
%ERRCODE%:
NTP server setting is not correct. Print JOB is canceled
because it judged that the correct time is impossible to
enter. Users need to change the setting of NT server.
430 %TRAY% missing.
Please close %TRAY%.
To cancel
Select [Cancel]
Indicates that paper feed is unavailable in attempting to
print from Tray 1 due to removal of the paper cassette of
Tray 1.
%TRAY%
Tray1
Note! If the paper cassette of the tray is removed
during displaying paper request (no.124, 125), system
will display that tray is removed (this display)
Error Code
Displayed message Descriptions
431 %TRAY% missing.
Please close %TRAY%.
To cancel
Select [Cancel]
Indicates that paper feed is unavailable in attempting to
print from Tray 2 due to removal of the paper cassette of
Tray 2.
%TRAY%
Tray2
Note! If the paper cassette of the tray is removed
during displaying paper request (no.124, 125), system
will display that tray is removed (this display)
440
441
%TRAY% missing.
Please close %TRAY%.
To cancel
Select [Cancel]
Indicates removal of the paper cassette of Tray 1 that is
a paper path in attempting to print from Tray 2.
%TRAY%
Tray1
Tray2
460 %TRAY% Media
Mismatch.
On %TRAY%
Please set
paper(%MEDIA_SIZE%
%MEDIA_TYPE%).
To cancel
Select [Cancel]
The media type in the tray and the print data do not
match.
Load paper that was set in %MEDIA_SIZE% and
%MEDIA_TYPE% in tray.
%TRAY%
MPTray
Paper size displays in Custom mode:
"<width>x<length><unit>"
ex.) 210x297MM
8.5x11.0INCH
The unit of paper size in Custom: The unit specified for
MPTray (menu setting) is used if no unit is specified by
the driver. When the driver specifies a unit, the unit is
used for display.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
