Macro Reference
385
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Cont
Resumes execution of the
program after it has been
stopped
Debug
Command
OK OK OK OK
Reference: X
Details (p.436)
CopyMeasur
eImage
Copies the measurement image
as an image of the Unit Macro
processing unit
Processing unit
control
--- --- --- OK
Reference: X
Details (p.438)
CopyScene Copies scene data Scene control --- OK OK ---
Reference: X
Details (p.440)
CopySceneG
roup
Copies scene group data
Scene group
control
--- OK OK ---
Reference: X
Details (p.441)
CopyUnit Copies a processing unit Flow control --- OK OK ---
Reference: X
Details (p.442)
CopyUnitFigu
re
Copies figure data to the
processing unit
Processing unit
control
--- OK OK OK
Reference: X
Details (p.444)
CopyUnitIma
ge
Copies a processing unit image
as a unit macro processing unit
Processing unit
control
--- --- --- OK
Reference: X
Details (p.446)
CopyUnitMod
el
Copies the model data of a
processing unit
Processing unit
control
--- OK OK OK
Reference: X
Details (p.448)
Cos
Gets the cosine of the specified
expression
Arithmetic
Calculation
OK OK OK OK
Reference: X
Details (p.450)
Crspoint
Gets the intersection between 2
straight lines
Arithmetic
Calculation
OK OK OK OK
Reference: X
Details (p.452)
Date$
Reads out the date from the
internal clock
Arithmetic
Calculation
OK OK OK OK
Reference
: X
Details (p.454)
Debug
Set the program execution form
and information output method
Debug
Command
OK OK OK OK
Reference: X
Details (p.456)
DebugPrint
Outputs debug information to
the system status console
window
Debug
Command
OK OK OK OK
Reference: X
Details (p.458)
DeleteUnit Deletes a processing unit Flow control --- OK OK ---
Reference: X
Details (p.460)
Dim Defines the array variable
General
instruction
OK OK OK OK
Reference: X
Details (p.461)
DisplaySubN
o
Get the sub-image number of
the displayed sub-image
Image Window
Control
--- --- --- OK
Reference: X
Details (p.462)
DisplayUnitN
o
Gets the selection state of the
processing unit number of the
flow window
Display control --- OK OK ---
Reference: X
Details (p.464)
Do Loop
While
Repeatedly executes the
statements between Do and
Loop while the specified
condition meets
General
instruction
OK OK OK OK
Reference: X
Details (p.465)
Dposline
Gets the shortest distance
between the line and point
Arithmetic
Calculation
OK OK OK OK
Reference: X
Details (p.467)
DrawArc
Draw the arc on the image
window
Image Window
Control
--- --- --- OK
Reference: X
Details (p.469)
Command
Name
Function Classification
Unit
Calculat
ion
Macro
Scene
Control
Macro
Commu
nication
Comma
nd
Macro
Unit
Macro
