Macro Reference
764
Vision System FH/FZ5 Series
User’s Manual (Z340)
Example
Transforms the value of the measurement angle before calibration measured with the search processing unit
of Processing Unit number 2 is applied, to the angle value after calibration is applied. "Measurement angle" is
the external reference data identification name "angle".
Useable Modules
Unit Calculation Macro / Unit Macro
Supported Versions
Version 3.50 or later
Related Items
Rem Get the measurement result.
GetUnitData 2, "angle", BEFOREANGLE#
Rem Transform to the value after calibration is applied.
TransformAngle 2, 0, 10, BEFOREANGLE#, AFTERANGLE#
GetUnitData (Reference: X Details (p.552)) TransformArea (Reference: X Details (p.765))
TransformDist (Reference: X Details (p.767)) TransformLine (Reference: X Details (p.769))
TransformXY (Reference: X Details (p.771)) UnitNo (Reference: X Details (p.790))
Ut (Reference: X Details (p.793))
