Macro Reference
766
Vision System FH/FZ5 Series
User’s Manual (Z340)
Example
Transforms the value of the area before calibration measured with the labeling processing unit of Processing
Unit number 2 is applied, to the area value after calibration is applied. "Area" is the external reference data
identification name "area".
Useable Modules
Unit Calculation Macro / Unit Macro
Supported Versions
Version 3.50 or later
Related Items
Rem Get the measurement result.
GetUnitData 2, "area", BEFOREAREA#
Rem Transform to the value after calibration is applied.
TransformArea 2, 0, 10, BEFOREAREA#, AFTERAREA#
GetUnitData (Reference: X Details (p.552)) TransformAngle (Reference: X Details (p.763))
TransformDist (Reference: X Details (p.767)) TransformLine (Reference: X Details (p.769))
TransformXY (Reference: X Details (p.771)) UnitNo (Reference: X Details (p.790))
Ut (Reference: X Details (p.793))
