Macro Reference
768
Vision System FH/FZ5 Series
User’s Manual (Z340)
Example
Transforms the distance value of the average width before calibration is applied, which is measured with the
scan edge width processing unit of Processing Unit number 2, to the distance value after calibration is
applied. The "average width" is external reference data identification name "width ave".
Useable Modules
Unit Calculation Macro / Unit Macro
Supported Versions
Version 3.50 or later
Related Items
Rem Get the measurement result.
GetUnitData 2, "width_ave", BEFOREDIST#
Rem Transform to the value after calibration is applied.
TransformDist 2, 0, 10, BEFOREDIST#, AFTERDIST#
GetUnitData (Reference: X Details (p.552)) TransformAngle (Reference: X Details (p.763))
TransformArea (Reference: X Details (p.765)) TransformLine (Reference: X Details (p.769))
TransformXY (Reference: X Details (p.771)) UnitNo (Reference: X Details (p.790))
Ut (Reference: X Details (p.793))
