Macro Reference
772
Vision System FH/FZ5 Series
User’s Manual (Z340)
Usage Cautions
• None.
Example
Transforms the pre-calibration measurement coordinates measured with the search processing unit of
Processing Unit 2 to the measurement coordinates after calibration is applied. "Measurement coordinate X"
is the external reference data identification name "positionX", and "measurement coordinate Y" is the
external reference data identification name "positionY".
Useable Modules
Unit Calculation Macro / Unit Macro
Supported Versions
Version 3.50 or later
Related Items
Rem Get the measurement result.
GetUnitData 2, "positionX", BEFOREX#
GetUnitData 2, "positionY", BEFOREY#
Rem Transform to the value after calibration is applied.
TransformXY 2, 0, 10, BEFOREX#, BEFOREY#, AFTERX#, AFTERY#
GetUnitData (Reference: X Details (p.552)) TransformAngle (Reference: X Details (p.763))
TransformArea (Reference: X Details (p.765)) TransformDist (Reference: X Details (p.767))
TransformLine (Reference: X Details (p.769)) UnitNo (Reference: X Details (p.790))
Ut (Reference: X Details (p.793))
