9.2 EMC measures
Mains filter
In this chapter you can read about:
..................................................................................................................... 173
Motor output filter ........................................................................................................... 178
Mains filters ................................................................................................................... 180
9.2.1. Mains filter
For radio disturbance suppression and for complying with the emission limit values
for CE conform operationwe offer mains filters:
Observe the maximum permitted length of the connection between the mains filter
and the device:
 unshielded <0.5m;
 shielded: <5m (fully shielded on ground e.g. ground of control cabinet)
Order code mains filter Compax3S
/
for C3S025V2 or S063V2
NFI 0 1 / 0 1
for C3S0xxV4, S150V4 or S1xxV2
NFI 0 1 / 0 2
for C3S300V4
NFI 0 1 / 0 3
Order Code mains filter PSUP
/
for PSUP10
Reference axis combination 3x480V 25A
6x10m motor cable length
NFI 0 3 / 0 1
for PSUP10
Reference axis combination 3x480V 25A
6x50m motor cable length
NFI 0 3 / 0 2
for PSUP20 & PSUP30
Reference axis combination 3x480V 50A
6x50m motor cable length
NFI 0 3 / 0 3
Order code for mains filters
for PSUP30 Mains filter
LCG-0055-0.45 mH
for PSUP30 Mains filter with UL approval
LCG-0055-0.45 mH-UL
Order code mains filter Compax3H
/
for C3H050V4
NFI 0 2 / 0 1
for C3H090V4
NFI 0 2 / 0 2
for C3H1xxV4
NFI 0 2 / 0 3

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
