Parker EME
Setting up Compax3
192-120100 N16 C3I10T10 - December 2010
4.4.5. Input simulation
Calling up the input simulation
In this chapter you can read about:
.......................................................................................139
Operating Principle ........................................................................................................140
The input simulation is used for the performance of tests without the complete
input/output hardware being necessary.
The digital inputs (standard and inputs of M10/M12 option) as well as the analog
inputs are supported.
The following operating modes are available for digital inputs:
ļµ The physical inputs are deactivated, the digital inputs are only influenced via the
input simulation.
ļµ The digital inputs and the physical inputs are logically or-linked.
This necessitates very careful action, as the required function is, above all with
low-active signals, no longer available.
The pre-setting of an analog input value is always made in addition to the physical
analog input.
The function of the inputs depends on the Compax3 device type; please refer to
the respective online help or the manual.
The input simulation is only possible if the connection with Compax3 is
active and if the commissioning mode is deactivated!
4.4.5.1 Calling up the input simulation
Open the optimization window (double click in the C3 ServoManager tree entry:
Optimization).
Activate the Tab āSetupā in the right lower window.
Clicking on the following button will open a menu; please select the input
simulation.
