Compax3 Accessories
C3I10T10
182
192-120100 N16 C3I10T10 - December 2010
9.3.1. Resolver cable
12
11
12
11
5
2
1
10
7
Ref+
Ref-
9
8
+Temp
-Temp
COS-
COS+
SIN-
SIN+
2x0,25
2x0,25
2x0,25
2x0,25
Pin 1
4
REFres+
REFres-
10
+5V
Tmot
COS-
COS+
SIN-
SIN+
4
NC
NC
NC
5
3
NC
6
7
8
15
13
14
9
NC
NC
NC
NC
NC
2
3
6
NC
1
NC
Resolver
GY
PK
GN
RD
BU
WH
BN
YE
GY
PK
GN
RD
BU
WH
BN
YE
Compax3 (X13)
27mm
Lƶtseite / solder side
Crimpseite / crimp side
Codiernut S = 20°
9
8
7
6
5
4
3
2
1
12
11
10
15
14
13
12
11
6
9
8
7
10
5
4
3
2
1
Lƶtseite
solder side
2 mm 6 mm
23 mm
Schirm auf Schirmanbindungselement
Screen at screen contact
REK42/..
The same cable (with changed conductor coloring) is available under the
designation REK41/.. in a version which is suitable for cable chain systems.
You can find the length code in the Chapter Order Code Accessories (see on
page 166).
