Parker EME
Communication
192-120100 N16 C3I10T10 - December 2010
153
5.1.8. C3 settings for RS485 four wire operation
C3 ServoManager RS485 wizard settings:
download with configuration in RS232 mode
Communication settings C3S/C3M:
Object
Function
Value
810.1 Protocol 0 (4 wire)
810.2 Baud rate 115200
810.3 NodeAddress 1..254
810.4 Multicast Address
