Compax3 Accessories
C3I10T10
206
192-120100 N16 C3I10T10 - December 2010
9.8.2. RS485 cable to Pop
5
3
Pin 1
7
Pin 1
4 mm 6 mm
26 mm
7 - 13
1 - 4
15
Lƶtseite
solder side
1
2
3
4
5
6
7
8
9
NC
NC
NC
LƤnge / Length A
LƤnge / Length B
Pin 1
Pin 1
LƤnge / Length B
5
3
7
1
NC 2,4,6,8
TxD_RxD
GND
Lƶtseite
solder side
1
2
3
4
5
6
7
8
9
BN
WH
GN
YE
TxD_RxD
TxD_RxD
GND
TxD_RxD
CHA+
CHA-
GND
BN
WH
GN
YE
9
BN
WH
YE
1
NC 2,4,6,8
9
RD
RD
X2
X3
X4
14
6
5
R21 nur im letzten Stecker
8
11
15
R21 only on the last connector
Schirm großflächig auf Gehäuse legen
Place sheath over large area of housing
Schirm großflächig auf Gehäuse legen
Place sheath over large area of housing
Brücke /
Bridge
Brücke /
Bridge
Schirm großflächig auf Gehäuse legen
Place sheath over large area of housing
Compax3_n
Compax3_2
Compax3_1
SSK27: Connection Pop - Compax3 - Compax3 - ...
R21 = 220 Ohm
Length A (Pop - 1. Compax3) variable (the last two numbers according to the
length code for cable, for example SSK27/nn/01)
(6
Order code: SSK27/nn/..
Length B (1. Compax3 - 2. Compax3 - ... - n. Compax3) fixed 50 cm (only if there is
more than 1 Compax3, i.e. nn greater than 01)
Number n (the last two digits)
Examples include:
SSK27/05/.. for connecting from Pop to 5 Compax3.
SSK27/01/.. for connecting from Pop to one Compax3
