Parker EME
Compax3 Accessories
192-120100 N16 C3I10T10 - December 2010
201
9.5 Condenser module C4
Order code condenser module
for C3S300V4 1100ĀµF
Modules
C4
Technical Characteristics
Type
Capacity Cable length
Module C4
1100ĀµF ~30 cm
Dimensions in mm
Module C4 A B C C1 D E F G H
430 190 90 120 370 15 18 30
āˆ… 6
