8.2 Order code for mains module: PSUP
Example: PSUP10D6USBM00
PSU
P D6 USB M00
Power module P
Nominal power; supply voltage
10kW; 400 VAC (3-phase) 10 D6
20kW; 400 VAC (3-phase) 20 D6
30kW; 400 VAC (3-phase) 30 D6
Interface:
USB connection USB
Options:
no additional supplement M00
8.3 Order code for accessories
Order Code connection set for Compax3S
The corresponding connection sets are furnished with the device. /
for C3S0xxV2 ZBH 02/01
ZBH 0 2 / 0 1
for C3S0xxV4 / S150V4 / S1xxV2 ZBH 02/02
ZBH
0 2 / 0 2
for C3S300V4 ZBH 02/03
ZBH 0 2 / 0 3
Order code for PSUP/Compax3M connection set
The corresponding connection sets are furnished with the device. /
for C3M050D6, C3M100D6, C3M150D6 ZBH 04/01
ZBH 0 4 / 0 1
for C3M300D6 ZBH 04/02
ZBH
0 4 / 0 2
for PSUP10 ZBH 04/03
ZBH 0 4 / 0 3
PSUP20, PSUP30 ZBH 04/04
ZBH
0 4 / 0 4
Order code for feedback cables
/
for resolver
(2
for MH / SMH motors
REK 4 2 / ... ...
(1
for resolver
(2
for MH / SMH motors (cable chain compatible)
REK 4 1 /
... ...
(1
for SinCos© – feedback
(2
for MH / SMH motors (cable chain compatible)
GBK 2 4
/
.. ...
(1
for EnDat 2.1
(2
for MH / SMH motors (cable chain compatible)
GBK
3 8 / .. ...
(1
Encoder – Compax3
GBK 2 3 / ... ...
(1
for LXR linear motors (cable chain compatible)
GBK 3 3 /
... ...
(1
for BLMA linear motors (cable chain compatible)
GBK 3 2 / ... ...
(1
(x
Note on cable (see on page 169)
Motor cable order code
(2
/
for SMH / MH56 / MH70 / MH105
(3
(1.5mm
2
; up to 13.8A)
MOK 5 5 / ... ...
(1
for SMH / MH56 / MH70 / MH105
(3
(1.5mm
2
; up to 13.8A) (cable chain compatible)
MOK 5 4 /
... ...
(1
for SMH / MH56 / MH70 / MH105
(3
(2.5mm
2
; up to 18.9A)
MOK 5 6 / ... ...
(1
for SMH / MH56 / MH70 / MH105
(3
(2.5mm
2
; up to 18.9A) (cable chain compatible)
MOK
5 7 / ... ...
(1
for MH145 / MH205
(4
(1.5mm
2
; up to 13.8A)
MOK 6 0 / ... ...
(1
for MH145 / MH205
(4
(1.5mm
2
; up to 13.8A) (cable chain compatible)
MOK
6 3 / ... ...
(1
for MH145 / MH205
(4
(2.5mm
2
; up to 18.9A)
MOK 5 9 / ... ...
(1
for MH145 / MH205
(4
(2.5mm
2
; up to 18.9A) (cable chain compatible)
MOK
6 4 / ... ...
(1
for MH145 / MH205
(4
(6mm
2
; up to 32.3A) (cable chain compatible)
MOK 6 1 / ... ...
(1
for MH145 / MH205
(4
(10mm
2
; up to 47.3A) (cable chain compatible)
MOK 6 2 /
... ...
(1
