1.7.3. Conditions of utilization for UL certification Compax3M
UL-approval for PSUP/Compax3M
conform to UL:

according to UL508C
Certified

E-File_No.: E235342
The UL certification is documented
by a “UL” logo on the device (type
specification plate).
Conditions of utilization
 The devices are only to be installed in a degree of contamination 2 environment
(maximum).
 The devices must be appropriately protected (e.g. by a switching cabinet).
 Tightening torque of the field wiring terminals ( green Phoenix plugs)
Device X40: Ballast resistor X41: Mains connector X9: 24VDC
PSUP10
0.5 Nm (4.43Lb.in) 1.2 Nm (10.62Lb.in)
1.2 Nm
(10.62Lb.in)
PSUP20
0.5 Nm (4.43Lb.in) 1.7 Nm (15Lb.in)
1.2 Nm
(10.62Lb.in)
PSUP30
UL approval in preparation
Device X43: Motor connector X15: Temperature monitoring
C3M050-150
0.5Nm (4.43Lb.in) 0.22Nm (1.95Lb.in)
C3M300
1.2Nm (10.62Lb.in) 0.22Nm (1.95Lb.in)
 Temperature rating of field installed conductors shall be at least 60°C Use copper
lines only
Please use the cables described in the accessories chapter (see on page 165,
see on page 166), they feature a temperature rating of at least 60°C.
 Maximum Surrounding Air Temperature: 40°C.
 Suitable for use on a circuit capable of delivering not more than 5000 rms
symmetrical amperes and 480 volts maximum.
Caution!
Danger of electric shock.
Discharge time of the bus capacitor is 10 minutes.
 The drive provides internal motor overload protection.
This must be set so that 200% of the motor nominal current are not exceeded.
 Cable cross-sections
 Mains input: corresponding to the recommended fuses.
 Motor cable: corresponding to the Nominal output currents (see on page 213,
see on page 214)
 Maximum cross-section limited by the terminals mm
2
/ AWG
Compax3 device:
Line cross-sections of the power connections (on the device bottoms)
Cross-section: Minimum... Maximum [with conductor sleeve]
M050, M100, M150
0.25 ... 4 mm
2
(AWG: 23 ... 11)
M300
0.5 ... 6 mm
2
(AWG: 20 ... 10)
PSUP10
Mains supply: 0.5 ... 6 mm
2
(AWG: 20 ... 10)
Braking resistor: 0.25 ... 4 mm
2
(AWG: 23 ... 11)
PSUP20 & PSUP30
Mains supply: 0.5 ... 16 mm
2
(AWG: 20 ... 6)
Braking resistor: 0.25 ... 4 mm
2
(AWG: 23 ... 11)
