Parker Compax3 I10T10 User Manual

Technical Characteristics
C3I10T10
214
192-120100 N16 C3I10T10 - December 2010
Output data Compax3Mxxx at 3*230VAC
Device type Compax3 M050D6 M100D6 M150D6 M300D6
Input voltage
325VDC ±10%
Output voltage
3x 0-230V (0...500Hz)
Nominal output current
5Arms 10Arms 15Arms 30Arms
Pulse current for 5s*
10Arms 20Arms 30Arms 60Arms
Power
2kVA 4kVA 6kVA 12kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
70W+** 90W+** 120W+** 270W+**
*Electrical turning frequency for pulse current: f>5 Hz; with an electrical turning frequency of f<5 Hz, the
maximum pulse current time is 100ms
** Maximum additional losses with option card 5 W.
Output data Compax3Mxxx at 3*400VAC
Device type Compax3 M050D6 M100D6 M150D6 M300D6
Input voltage
565VDC ±10%
Output voltage
3x 0-400V (0...500Hz)
Nominal output current
5Arms 10Arms 15Arms 30Arms
Pulse current for 5s*
10Arms 20Arms 30Arms 60Arms
Power
3.33kVA 6.66kVA 10kVA 20kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
70W+** 90W+** 120W+** 270W+**
*Electrical turning frequency for pulse current: f>5 Hz; with an electrical turning frequency of f<5 Hz, the
maximum pulse current time is 100ms
** Maximum additional losses with option card 5 W.
Output data Compax3Mxxx at 3*480VAC
Device type Compax3 M050D6 M100D6 M150D6 M300D6
Input voltage
680VDC ±10%
Output voltage
3x 0-480V (0...500Hz)
Nominal output current
4Arms 8Arms 12.5Arms 25Arms
Pulse current for 5s*
8Arms 16Arms 25Arms 50Arms
Power
3.33kVA 6.66kVA 10kVA 20kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
70W+** 90W+** 120W+** 270W+**
*Electrical turning frequency for pulse current: f>5 Hz; with an electrical turning frequency of f<5 Hz, the
maximum pulse current time is 100ms
** Maximum additional losses with option card 5 W.

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
