Technical Characteristics
192-120100 N16 C3I10T10 - December 2010
215
Output data Compax3Hxxx at 3*400VAC
Controller type
H050V4
H090V4
H125V4
H155V4
Output voltage
3x 0-400V
Nominal output current
50Arms 90Arms 125Arms 155Arms
Pulse current for 5s *
75Arms 135Arms 187.5Arms 232.5Arms
Power
35kVA 62kVA 86kVA 107kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
880W 900W 1690W 1970W
* during low speeds, the overload time is reduced to 1s. Limit:
< 2.5 electric rev/s (= actual revolutions/s * number of pole pairs) resp. >2.5 pitch/s
Output data Compax3Hxxx at 3*480VAC
Controller type
H050V4
H090V4
H125V4
H155V4
Output voltage
3x 0-480V
Nominal output current
43Arms 85Arms 110Arms 132Arms
Pulse current for 5s*
64.5Arms 127.5Arms 165Arms 198Arms
Power
35kVA 70kVA 91kVA 109kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
850W 1103W 1520W 1800W
* during low speeds, the overload time is reduced to 1s. Limit:
< 2.5 electric rev/s (= actual revolutions/s * number of pole pairs) resp. >2.5 pitch/s
