Compax3 device description
192-120100 N16 C3I10T10 - December 2010
95
3.10.3.7 Technical details of the Compax3M S1 option
Safety technology Compax3M
Safe torque-off in accordance with EN
ISO 13849-1: 2007, Category 3, PL=e
Certified.
Test mark MFS 09029

Please respect the stated safety
technology on the type designation
plate (see on page
11) and the circuitry
examples (see on page 87)
Compax3M S1 Option: Signal inputs for connector X14
Nominal voltage of the
inputs
24V
Required isolation of the
24V control voltage
Grounded protective extra low voltage, PELV
Protection of the STO
control voltage
1A
Number of inputs
Signal inputs via
optocoupler
2
Low = 0...7V DC or open
High = 15...30V DC
I
in
at 24V DC: 8mA
STO1/
Low = STO activated
High = STO deactivated
Reaction time max. 3ms
STO2/
Low = STO activated
High = STO deactivated
Reaction time max. 3ms
Switch-off time with
unequal input statuses
(max. reaction time)
20 seconds
Grouping of safety level
Category 3
PL=e
(according to table 4 in EN ISO 13849-1 this
corresponds to SIL 3)
PFHd=4.29E-8
