Compax3 device description
192-120100 N16 C3I10T10 - December 2010
27
3.2 Meaning of the status LEDs - PSUP (mains module)
PSUP Status LEDs Left LED (green) Right LED (red)
Control voltage 24 VDC is missing off off
Error of mains module* off on
DC power voltage is built up - flashes quickly
Phase failure / mains power supply undervoltage on flashes slowly
Address assignment CPU active flashes quickly -
Address assignment CPU completed flashes slowly -
PSUPxx Ready - State on off
Incorrect wiring of internal communication X30/31 flashes slowly flashes quickly
Device in bootloader state flashes slowly flashes slowly
*can be read out in each axis controller
Caution!
When the control voltage is missing there is no indication whether or not high
voltage supply is available.

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
