Compax3 device description
C3I10T10
58
192-120100 N16 C3I10T10 - December 2010
3.6.8.3 Connection of the power voltage of 2 C3H 3AC
devices
In order to improve the conditions during brake operation, the DC power voltage of
2 servo axes may be connected.
The capacity as well as the storable energy are increased; furthermore the braking
energy of one servo axis may be utilized by a second servo axis, depending on the
application.
It is not permitted to connect the power voltage in order to use one brake
circuit for two servo axes, as this function cannot be ensured reliably.
Caution! In case of non-compliance with the following instructions, the
device may be destroyed!
Note the following:
 You can only connect two similar servo axes (same power supply; same rated
currents)
 Connected servo axes must always be fed separately via the AC power supply.
 If the external pre-fuse of one of the servo axes takes action, the second servo
axis must also be disconnected automatically.
Please connect as follows:
Servo axis 1 DC+ with servo axis 2 DC+
Servo axis 1 DC- with servo axis 2 DC-
- figure (see on page 51)

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
