Parker Compax3 I10T10 User Manual

Technical Characteristics
C3I10T10
210
192-120100 N16 C3I10T10 - December 2010
Mains connection Compax3S0xxV2 1AC
Controller type
S025V2
S063V2
Supply voltage
Single phase 230VAC/240VAC
80-253VAC / 50-60Hz
Input current
6Arms 13Arms
Maximum fuse rating per device
(=short circuit rating)
10 A (MCB miniature
circuit breaker, K
characteristic)
16A (automatic circuit
breaker K)
Mains connection Compax3S1xxV2 3AC
Controller type
S100V2
S150V2
Supply voltage
Three phase 3* 230VAC/240VAC
80-253VAC / 50-60Hz
Input current
10Arms 13Arms
Maximum fuse rating per device
(=short circuit rating)
16A 20A
MCB miniature circuit breaker, K characteristic
Mains connection Compax3SxxxV4 3AC
Controller type
S015V4
S038V4
S075V4
S150V4
S300V4
Supply voltage
Three phase 3*400VAC/480VAC
80-528VAC / 50-60Hz
Input current
3Aeff 6Arms 10Arms 16Arms 22Arms
Maximum fuse rating per
device(=short circuit
rating)
6A 10A 16A 20A 25A
MCB miniature circuit breaker, K characteristic D*
10. Technical Characteristics

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
