Setting up Compax3
192-120100 N16 C3I10T10 - December 2010
117
4.4.1. Optimization window
Layout and functions of the optimization window
Segmentation
Functions (TABs)
Window1:

Oscilloscope (see on page 118)
Window 2:

Optimization: Controller optimization (see on page 129)
 D/A Monitor (see on page 163): Output of status values via 2
analog outputs

Scope Settings
Window 3:

Status Display

Compax3 Error History
Window 4:

Status values
 Commissioning: Setup mode (see on page 141) with load
identification (see on page 126)
 Parameters for commissioning, test movements (relative &
absolute) and for load identification.
