Compax3 device description
C3I10T10
38
192-120100 N16 C3I10T10 - December 2010
3.4 Installation instructions Compax3M
General introductory notes
 Operation of the Compax3M multi-axis combination is only possible in connection
with a PSUP (mains module).
 Axis controllers are aligned at the right of the mains module.
 Arrangement within the multi-axis combination sorted by power (with the same
device types according to device utilization), the axis controller with the highest
power is placed directly at the right of the mains module.
e.g. first the device type with high utilization, at the right of this, the same device
type with a lower utilization.
 Max. 15 Compax3M (axis controllers) per PSUP (mains module) are permitted
(please respect the total capacity of max. 2400µF for PSUP10, max. 5000µF for
PSUP20).
 The continuation of the current rail connection outside the axis combination is not
permitted and will lead to a loss of the CE and UL approbation.
 External components may not be connected to the rail system.
Required tools:
 Allen key M5 for fixing the devices in the control cabinet.
 Crosstip screwdriver M4 for connection rails of the DC rail modules.
 Crosstip screwdriver M5 for grounding screw of the device.
 Flat-bladed screwdriver 0.4x2.5 / 0.6x3.5 / 1.0x4.0 for wiring and mounting of the
phoenix clamps.
