Compax3 device description

192-120100 N16 C3I10T10 - December 2010

3.10.3.4 STO delay times

Input

Energize

Speed

t_deceleration

(Configurable in Drive)

t_delay_time

(Configurable in UE410)

t_delay_STO ≤ 3ms

Input

STO1/, STO2/

Torqueless

Motor
