Parker Compax3 I10T10 User Manual

Parker EME
Compax3 Accessories
192-120100 N16 C3I10T10 - December 2010
209
9.8.6. Modem cable SSK31
Schirm großflächig auf Gehäuse legen
Place sheath over large area of housing
RxD
Pin 1
Modem
WH
GN
YE
BN
Compax3 (X10)
Schirm großflächig auf Gehäuse legen
Place sheath over large area of housing
Pin 1
TxD
GND
5
2
Lötseite
solder side
1
2
3
4
5
6
7
8
9
4 mm 6 mm
26 mm
5
2
3
RxD
TxD
GND
4
NC
1,6,7,9
3
WH
GN
YE
BN
NC
1,6,7,9
8
brücken (Litze 0,25)
connect (wire 0,25)
4
8
Lötseite
solder side
1
2
3
4
5
6
7
8
9
brücken (Litze 0,25)
connect (wire 0,25)
SSK31/..
You can find the length code in the Order Code Accessories (see on page 166)

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
