Parker Compax3 I10T10 User Manual

Parker EME
Introduction
192-120100 N16 C3I10T10 - December 2010
9
Device assignment
In this chapter you can read about:
............................................................................................................ 9
Scope of delivery ............................................................................................................. 10
Type specification plate ................................................................................................... 11
Packaging, transport, storage .......................................................................................... 12
Safety instructions ........................................................................................................... 14
Warranty conditions ......................................................................................................... 16
Conditions of utilization .................................................................................................... 17
1.1 Device assignment
This manual is valid for the following devices:
 Compax3S025V2 + supplement
 Compax3S063V2 + supplement
 Compax3S100V2 + supplement
 Compax3S150V2 + supplement
 Compax3S015V4 + supplement
 Compax3S038V4 + supplement
 Compax3S075V4 + supplement
 Compax3S150V4 + supplement
 Compax3S300V4 + supplement
 Compax3H050V4 + supplement
 Compax3H090V4 + supplement
 Compax3H125V4 + supplement
 Compax3H155V4 + supplement
 Compax3M050D6 + supplement
 Compax3M100D6 + supplement
 Compax3M150D6 + supplement
 Compax3M300D6 + supplement
 PSUP10D6
 PSUP20D6
With the supplement:
 F10 (Resolver)
 F11 (SinCos
©
)
 F12 (linear and rotary direct drives)
 I10 T10
1. Introduction

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
