Technical Characteristics
192-120100 N16 C3I10T10 - December 2010
213
Output data Compax3S0xx at 1*230VAC/240VAC
Controller type
S025V2
S063V2
Output voltage
3x 0-240V 3x 0-240V
Nominal output current
2.5Arms 6.3Arms
Pulse current for 5s
5.5Arms 12.6Arms
Power
1kVA 2.5kVA
Switching frequency
16kHz 16kHz
Power loss for In
30W 60W
Output data Compax3S1xx at 3*230VAC/240VAC
Controller type
S100V2
S150V2
Output voltage
3x 0-240V 3x 0-240V
Nominal output current
10Arms 15Arms
Pulse current for 5s
20Arms 30Arms
Power
4kVA 6kVA
Switching frequency
16kHz 8kHz
Power loss for In
80W 130W
Output data Compax3Sxxx at 3*400VAC
Controller type
S015V4
S038V4
S075V4
S150V4
S300V4
Output voltage
3x 0-400V
Nominal output current
1.5Arms 3.8Arms 7.5Arms 15Arms 30Arms
Pulse current for 5s
4.5Arms 9.0Arms 15Arms 30Arms 60Arms*
Power
1kVA 2.5kVA 5kVA 10kVA 20kVA
Switching frequency
16kHz 16kHz 16kHz 8kHz 8kHz
Power loss for In
60W 80W 120W 160W 350W
* With cyclic peak currents (S8 or S9 operation), the device utilization (683.2) may
not be > 70%; otherwise it is necessary to use a condenser module “C4Module
(see on page 201)”.
Output data Compax3Sxxx at 3*480VAC
Controller type
S015V4
S038V4
S075V4
S150V4
S300V4
Output voltage
3x 0-480V
Nominal output current
1.5Arms 3.8Arms 6.5Arms 13.9Arms 30Arms
Pulse current for 5s
4.5Arms 7.5Arms 15Arms 30Arms 60Arms*
Power
1.25kVA 3.1kVA 6.2kVA 11.5kVA 25kVA
Switching frequency
16kHz 16kHz 16kHz 8kHz 8kHz
Power loss for In
60W 80W 120W 160W 350W
* With cyclic peak currents (S8 or S9 operation), the device utilization (683.2) may
not be > 70%; otherwise it is necessary to use a condenser module “C4Module
(see on page 201)”.

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
