Order code
192-120100 N16 C3I10T10 - December 2010
167
Order Code braking resistors
/
for C3S063V2 or C3S075V4
56Ω / 0.18kW
cont.
BRM 0 5 / 0 1
for C3S075V4
56Ω / 0.57kW
cont.
BRM 0 5 / 0 2
for C3S025V2 or C3S038V4
100Ω / 60W
cont.
BRM 0 8 / 0 1
for C3S150V4
47Ω / 0.57kW
cont.
BRM 1 0 / 0 1
for C3S150V2, C3S300V4 and PSUP20D6
4/01:15Ω / 0.57kW
cont.
4/02:15Ω / 0.74kW
cont.
BRM 0 4 / 0 ...
for C3S300V4 and PSUP20D6
4/03:15Ω / 1.5kW
cont.
for C3S100V2
22Ω / 0.45kW
cont.
BRM 0 9 / 0 1
for C3H0xxV4
27Ω / 3.5kW
cont.
BRM 1 1 / 0 1
**for PSUP10D6 and PSUP20D6 2x30Ω parallel) 30Ω / 0.5kW
cont.
BRM 1 3 / 0 1
for PSUP10D6 (2x15Ω in series),
PSUP20D6, PSUP30D6
15Ω / 0.5kW
cont.
BRM 1 4 / 0 1
for C3H1xxV4, PSUP30D6
18Ω / 4.5kW
cont.
BRM 1 2 / 0 1
Order code mains filter Compax3S
/
for C3S025V2 or S063V2
NFI 0 1 / 0 1
for C3S0xxV4, S150V4 or S1xxV2
NFI 0 1 / 0 2
for C3S300V4
NFI 0 1 / 0 3
Order code mains filter Compax3H
/
for C3H050V4
NFI 0 2 / 0 1
for C3H090V4
NFI 0 2 / 0 2
for C3H1xxV4
NFI 0 2 / 0 3
Order Code mains filter PSUP
/
for PSUP10
Reference axis combination 3x480V 25A
6x10m motor cable length
NFI 0 3 / 0 1
for PSUP10
Reference axis combination 3x480V 25A
6x50m motor cable length
NFI 0 3 / 0 2
for PSUP20 & PSUP30
Reference axis combination 3x480V 50A
6x50m motor cable length
NFI 0 3 / 0 3
Order code for mains filters
for PSUP30 Mains filter
LCG-0055-0.45 mH
for PSUP30 Mains filter with UL approval
LCG-0055-0.45 mH-UL
Order code for motor output filter (for Compax3S, Compx3M >20m motor cable)
/
up to 6,3 A rated motor current
MDR 0 1 / 0 4
Up to 16 A rated motor current
MDR
0 1 / 0 1
Up to 30A A rated motor current
MDR 0 1 / 0 2
Order code condenser module
for C3S300V4 1100µF Modules
C4

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
