Parker Compax3 I10T10 User Manual

Parker EME
Order code
192-120100 N16 C3I10T10 - December 2010
169
(1
Length code 1
Length [m] 1.0 2.5 5.0 7.5 10.0 12.5 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
Order code 01 02 03 04 05 06 07 08 09 10 11 12 13 14
Example:
SSK01/09: Length 25m
(2
Colors according to DESINA
(3
with motor connector
(4
with cable eye for motor terminal box
5
length code 2 for SSK28
Length [m] 0.17 0.25 0.5 1.0 3.0 5.0 10.0
Order code 23 20 21 01 22 03 05
Length A (Pop - 1. Compax3) variable (the last two numbers according to the
length code for cable, for example SSK27/nn/01)
(6
Order code: SSK27/nn/..
Length B (1. Compax3 - 2. Compax3 - ... - n. Compax3) fixed 50 cm (only if there is
more than 1 Compax3, i.e. nn greater than 01)
Number n (the last two digits)
Examples include:
SSK27/05/.. for connecting from Pop to 5 Compax3.
SSK27/01/.. for connecting from Pop to one Compax3
MOK55 and MOK54 can also be used for linear motors LXR406, LXR412 and
BLMA.
(x
Note on cable (see on page 169)

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
