23.Torque front drive isolator bolts
g
to specification.
TORQUE
Front Drive Isolator Bolts:
55 ft-lbs (75 Nm) + 180°
24.Torque the front drive mounting bracket fasteners
h
.
TORQUE
Front Drive Mounting Bracket Fasteners (Front):
Vehicles built before 01/07/2019:18 ft-lbs (24 Nm)
Vehicles built on, or after 01/07/2019: 25 ft-lbs (34 Nm)
25.Route vent line through routing grommet
j
and
connect to front gearcase
k
.
26.Install the winch mounting plate and fasteners
l
.
Torque to specification.
TORQUE
Winch Mounting plate Fasteners:
18 ft-lbs (24 Nm)
