Replacing Wear Items

QL-300 User Guide 327

Also, a new waste toner box is mounted inside the belt unit.

1 If roll paper has been fed through the printer, press the UNLOAD button to cut the roll

paper.

The cut paper will be fed to the supply side and the feeding side.

2 Grasp the top cover open lever and open the top cover.
