Web Utility
QL-300 User Gu
ide
443
To send periodic noti
fications about problems
1
Log in as an administrator.
See “Loggin
g in as an Administrator” on page 405.
2
Click:
Admin Setup > Network Setup
.
3
Click:
Email > Alert Settings
.
442
444
