Print Function Settings

QL-300 User Guide 145

Menus

Unwinder Config

Item Value Description

Media Form Continuous Paper

Continuous Paper (Black

Mark)

Die-cut Label (Gap)

Die-cut Label (Black Mark)

Continuous Label

Continuous Label (Black

Mark)

Specifies the shape of the

roll paper.
