Specifications

QL-300 User Guide 480

Full sheet labels (normal printing)

Item Specification

Paper weight 0.07 to 0.25 mm (0.003 to 0.0098 inches)

Roll core Inner diameter: 76.2 mm (3 inches)

Outer diameter 203.2 mm (8 inches) or less
