Cleaning
QL-300 User Guide 365
17 Use a lint-free cloth moistened with alcohol to wipe the dirt off the sides of the paper guide
(1) and ends of the sheet guide (2).
18 Install the paper guide and secure the screw.
19 Remove the screws, two places, for the F0 roller unit.
20 Remove the F0 roller unit.
21 As you rotate the gears with one hand, use a lint-free cloth moistened with alcohol to clean
the top and bottom rollers on the F0 roller unit by wiping in just one direction.
Note: Lower the set lever on the rollers to rotate the top and bottom roller at the same time.
To Next Page
