Cleaning

QL-300 User Guide 371

6 Hold the belt unit handles (blue) on the left and right, and remove the belt unit at an angle.

Caution: Be careful not to spill waste toner while removing the belt unit.

Caution: Be careful to not pinch your hands or fingers between the handle and the

machine while removing the belt unit.

Caution: When removing the belt unit, do not tilt it further than is needed to remove it.

Default Chapter8
