ABL90 FLEX reference manual 2. Disk functions setup programs
2-5
Step Action
1. Press Change destination to choose the destination.
2. Highlight the drive or folder by touching it on the screen. Press
Expand/Collapse to open a folder in a directory or within a folder.
When completed, the correct destination appears in the upper part
of the box.
If a removable drive is used, connect it to the USB port
Press Back to return to the previous screen.
3. On the Backup all data screen press Start to continue.
4. The backup process begins.
Network drive or internal disk: Backup continues without any
further action from the operator
Removable drive: Wait for the data to be prepared (see the timer
in the current task field located next to the status indicator in the
upper left corner of the screen) and press Start.
5. If the analyzer status shows a "Backup done" message, the process
is complete. Press Close to return to the main screen.
