Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
930User Manual 1178.8520.02 ─ 01
Suffix:
<pb>
.
1..n
Selects the connector:
3 = RF
Return values:
<Type> String containing one of the following values:
–"None" (no probe detected)
–"active differential"
–"active single-ended"
–"active modular"
Example: //Query probe type
PROB3:SET:TYPE?
Usage: Query only
Manual operation: See "Type" on page 315
14.7.6.3
External Generator Control
External generator control commands are available if the R&S FSV/A External Genera-
tor Control option (R&S FSV3-B10) is installed.
For each measurement channel one external generator can be configured. To switch
between different configurations define multiple measurement channels.
For more information on external generator control see Chapter 8.2.4.2, "Basics on
External Generator Control", on page 325.
● Measurement Configuration..................................................................................930
● Interface Configuration..........................................................................................934
● Source Calibration.................................................................................................936
● Programming Example for External Generator Control........................................ 939
Measurement Configuration
The following commands are required to activate external generator control and to con-
figure a calibration measurement with an external tracking generator.
SOURce<si>:EXTernal<gen>:FREQuency........................................................................930
SOURce<si>:EXTernal<gen>:FREQuency:COUPling[:STATe]............................................ 931
SOURce<si>:EXTernal<gen>:FREQuency[:FACTor]:DENominator......................................931
SOURce<si>:EXTernal<gen>:FREQuency[:FACTor]:NUMerator......................................... 932
SOURce<si>:EXTernal<gen>:FREQuency:OFFSet........................................................... 932
SOURce<si>:EXTernal<gen>:POWer[:LEVel]................................................................... 933
SOURce<si>:EXTernal<gen>[:STATe].............................................................................. 933
SOURce<si>:POWer[:LEVel][:IMMediate]:OFFSet.............................................................934
SOURce<si>:EXTernal<gen>:FREQuency <Frequency>
This command defines a fixed source frequency for the external generator.
Suffix:
<si>
.
irrelevant
