2. Insert the original SD card in SD Card Slot 2. The application program is copied back into this card.
3. Insert the SD card with the application program in SD Card Slot 1.The application program is copied
back from this SD card.
4. Turn the main switch on.
5. Start the SP mode.
6. Select SP5-873-002 “Undo Exec.”
7. Follow the messages shown on the operation panel.
8. Turn the main switch off.
9. Remove the SD card from SD Card Slot 2.
• This step assumes that the application programs in the SD card are used by the machine.
10. Turn the main switch on.
11. Check that the application programs run normally.
12. Make sure that the machine can recognize the option (see ‘Check All Connections’ at the end of this
section).
PostScript 3
• Unplug the main machine power cord before you do the following procedure.
1. Remove the SD-card slot cover [A] from SD card slots ( x 1).
Controller Options
127
To Next Page
