5.
Drum/Development motor-K [B] (
x 4,
x 1)
ITB Drive Motor
1.
Rear cover (
*
"p.169")
2.
Open the controller box (
*
"p.287")
3.
ITB drive motor [A] (
x 4,
x 1)
Fusing/Paper Exit Motor
1.
Rear cover (
*
"p.169")
2.
Open the controller box (
*
"p.287")
4. Replacement and Adjustment
236
4
237
239
