Original Length/Width Sensors
1. Exposure glass with left scale (* p.175 "Exposure Glass")
2. Original length sensor bracket [A] ( x 1,  x1)
3. Original length sensors [B] (snap,  x 1 each)
4. The number of the original length sensors depends on the model; 3 for EU, 2 for others.
5. Original width sensors [C] (snap,  x 1,  x1 each)
Exposure Lamp
1. Rear cover (* p.169 "Rear Cover")
2. Operation panel (* p.171 "Operation Panel")
3. Exposure glass (* p.175 "Exposure Glass")
4. Replacement and Adjustment
176
4
