Ricoh MPC 2800 AT-C2 User Manual

1. Scanner HP sensor
2. ADF exposure glass
3. 2nd scanner (2nd carriage)
4. Exposure glass
5. 1st scanner (1st carriage)
6. Scanner lamp
7. Original width sensor
8. Original length sensor
9. Scanner motor
10. Lens block
11. Sensor board unit (SBU)
12. Decurler rollers
13. Duplex unit
14. Fusing unit
15. Paper transfer roller
16. Registration roller
17. By-pass feed table
18. Tray 2
19. Tray 1
20. Toner collection bottle
21. Laser optics housing unit
22. PCU (4 colors)
23. Image transfer belt cleaning unit
24. Image transfer belt unit
25. Toner bottle (4 colors)
26. ID sensor
Paper Path
Overview
15
1

Ricoh MPC 2800 AT-C2 Specifications

General

Brand	Ricoh
Model	MPC 2800 AT-C2
Category	All in One Printer
Language	English
